Lyton FX-11 Tunnel Car Wash System — Continuous 9/11-Brush Commercial Wash

Model

FX 11-9

FX 11-11

Quantity

Shipping to

Cannot be shipped to country

Please re-select the product or change the shipping country.

Core Specifications

120L

Water per Car

35kW

Power Consumption

9/11

Brush Configuration

380v

3-Phase Power

6Step

Wash Process

11.5×4×3.2m

Machine Footprint

Choose between the standard 9-brush and premium 11-brush configuration.

Specification	FX-11-9 Standard	FX-11-11 Premium
Brush Configuration	9 Brushes	11 Brushes
Machine Size (L×W×H)	11.5 × 4 × 3.2 m	11.5 × 4 × 3.2 m
Site Requirement	12 × 4 × 3.2 m	12 × 4 × 3.2 m
Max Vehicle Size	L unlimited × W2000 × H2000mm	L unlimited × W2000 × H2000mm
Power	380V / 35kW / 50Hz	380V / 35kW / 50Hz
Water Consumption	120 L / car	120 L / car
Wash Process	6-Step (High Pressure → Foam → Brush → Rinse → Wax → Air Dry)	6-Step (High Pressure → Foam → Brush → Rinse → Wax → Air Dry)
Recommended For	Standard commercial wash bays	Premium operators requiring extra coverage
Price	Request Quote	Request Quote

* Quotation includes installation, commissioning, and operator training. Excludes canopy, glass enclosure, air compressor, and shipping.
